Optoma ZU1700 WUXGA DLP laser projector with high brightness 17,000 lumens without lens

Name: Optoma ZU1700 WUXGA DLP laser projector with high brightness 17,000 lumens without lens
Brand: Optoma
SKU: ZU1700
Price: 23799.00 EUR
Availability: InStock

SKU:ZU1700

€23.799,00 EUR

Sale Sold out

Taxes included. Shipping calculated at checkout.

Delivery time 5 - 7 days *1

Quantity

Question about the product

Ultra-bright, professional WUXGA laser projector

The Optoma ZU1700 is a professional, high-brightness laser projector designed to meet the needs of high-end entertainment, exhibition, and digital signage installations.

As part of Optoma's Ultra Bright series, the ZU1700 offers an incredibly high brightness of 17,000 lumens as well as extreme flexibility with eight interchangeable lenses to meet the needs of even the most complex installations.
As part of the Optoma DuraCore laser line-up, the high-performance projector features 4K HDR compatibility, Pure Engine video processing, and color adjustment to produce visually stunning, lifelike images with exceptional detail and high color accuracy.

The ZU1700 is characterized by its high reliability. The laser projector can operate around the clock, has a laser lifetime of up to 30,000 hours, and is IP5X certified, ensuring optimal and reliable performance even under extreme conditions of up to 50 degrees Celsius.
Featuring a robust metal chassis and modular design for easier maintenance, a wide range of connectivity options, and a fail-safe redundancy mode for instant source switching, the Ultra Bright Series projector offers a solution for complicated installations, including multi-projector and dome projection applications.

WUXGA DLP laser projector with high brightness
17,000 lumens
Flexible installations
8 interchangeable lenses
Highest reliability
Integrated redundancy mode
Impressively lifelike images
Pure Engine video processing and color adjustment
Without lens

Specifications

Display technology

DLP

resolution

WUXGA (1920x1200)

brightness

17,000 lumens

ANSI lumen brightness

14,500

Contrast ratio

2,000,000

Aspect ratio

16:10

Compatible image formats

16:9,16:10

Screen size

Depending on the lens

light source

DuraCore Laser

LASER lifespan

30,000 hours

projection ratio

Depending on the lens

Projection distance (m)

Depending on the lens

Lens options

BX-CTA11, 0.65~0.75:1BX-CTA18, 0.84~1.02:1BX-CTA19, 1.02~1.36:1BX-CTA20, 1.2~1.5:1BX-CTA21, 1.5~2.0:1BX-CTA22, 2.0~4.0:1BX-CTA23, 4.0~7.2:1BX-CTA27, 7.2~10.8:1

Lens Shift

Yes -see documentation for details

Connections

Connections1 x RS232, 1 x 3D Sync, 1 x Wired Remote Control, 1 x HDBaseT, 1 x DisplayPort, 2 x HDMI, 1 x VGA, 1 x DVI-D, 1 x 3G-SDIExits1 x RS232, 1 x 3D Sync, 1 x Wired Remote Control, 1 x HDMI, 1 x 3G-SDIsteering1 x RJ45, 1 x USB-A service, 1 x 12V trigger

LAN - Wireless connection

Operating noise ECO

36 dB

Operating noise (max)

38 dB

3D

Full 3D

IP rating

OSD / Display Languages

11 languages: Dutch, English, French, German, Hungarian, Italian, Japanese, Norwegian, Polish, Portuguese, Spanish

24/7 operation

Yes

360° view

Yes

Operating conditions

Operating: 10~85%RH, non-condensing. Storage: 5~90%RH, non-condensing

remote control

Illuminated ProAV remote control

LAN - Display

Yes

LAN - Wireless connection

LAN

Yes

Power supply

AC 100–240 V @ 50/60 Hz

Power consumption (standby)

0.5W

Power consumption (min)

460W

Power consumption (max)

1,000W

Dimensions (W x D x H) (mm)

650 x 682 x 300.86

Gross weight

62.5 kg

Net weight

50 kg

Detailed information

DuraCore

Our projectors achieve industry-leading runtimes with Optoma DuraCore technology, featuring advanced laser diode cooling techniques and an innovative, dust-resistant design.

Redundant input with fast switching

The unique signal input detection feature ensures instant signal source switching should a device serving as the signal source fail. This feature ensures that an image is always displayed in mission-critical installations such as control rooms, live events, or other similar scenarios.

Passive 3D compatibility

Passive 3D is now available for single DLP chip laser phosphor projectors. Thanks to their highly efficient light output, these models enable effective 3D solutions for operators, reducing total cost of ownership.

Integrated warping and edge blending processor

The integrated warping and edge blending processor allows the images of multiple projectors to be aligned without additional hardware, thus reducing installation costs and effort. Warping and blending can be configured either via the on-screen menu or with PC software (depending on the model).

*Compatible graphics card with overlap function required.

Automatic color uniformity

The super-fast, camera-based automatic color matching feature enables quick, hassle-free, and convenient setup, delivering precise color matching in seconds.

*The automatic color uniformity function is compatible with image sizes up to 300".

Auto Focus (AF)

The super-fast, camera-based autofocus ensures quick, hassle-free, and convenient setup; you'll get a razor-sharp image in seconds.

*Autofocus is compatible with image sizes up to 300".

HDR compatible

Optoma's HDR-compatible projectors are capable of receiving and displaying HDR metadata. This allows you to see even more detail and texture. Objects are rendered more realistically, and these additional details create a greater sense of depth—as if you were looking through a window.

HDBaseT™

Send uncompressed Full HD video, audio, network, and control commands over a single CAT-type cable up to 100 meters without signal loss—for quick and easy installations. HDBaseT™ simplifies installation and saves time and money.

Metal housing with modular design

Modular metal housings and quick-release screws make routine maintenance easier than ever.

Amazing Color

Optoma projectors deliver reliable color performance for any content and any environment. From accurate sRGB colors to razor-sharp presentations, we have the display mode to suit your needs.

Color Management System (CMS)

Display lifelike colors with this feature. It offers the ability to precisely adjust colors for optimal precision.

Brightness adjustment

A valuable feature for any professional installation with more than one projector. Multiple units of the same model and similar lamp usage can be fine-tuned to deliver the same brightness levels. This is especially important when projecting side by side.

Constant Power

Allows the user to adjust the power levels to meet the individual requirements of the installation. Power levels can be adjusted to achieve the brightest image or the longest runtime of the light source—or anywhere in between.

Constant brightness

The advanced light-sensing technology allows for the setting of brightness levels that remain unchanged over time. Ideal for providing consistent brightness in finely tuned installations.

True AV Mute

True AV Mute allows you to turn the projector's light source on and off with the touch of a button. Unlike the standard AV Mute function, no light is emitted from the projector, ensuring a 100% black image.

Extreme Black

Extreme Black ensures that the laser diodes are completely switched off as soon as a completely black image frame is detected. This feature is perfect for situations where a total image blackout is necessary.

Full Lens Shift

Full lens shift offers a wider variety of placement options. This makes the projector easier to align and delivers a wider range of image sizes.

Picture by Picture Picture-in-Picture

Signals can be transmitted simultaneously via the HDMI and DVI ports to deliver PbP or PiP from two digital sources - perfect for video conferencing and other collaborative applications.

360 degree projections

Images can be projected over 360 degrees along the horizontal axis.

Portrait projection

Ideal for digital signage applications You can rotate your projector 90 degrees to project a portrait image.

Wide temperature range

Suitable for various operating environments. Thanks to the robust and efficient cooling system, the projector can operate in an ambient temperature range of 0~50°C.

Lens Shift

The lens shift simplifies your installations by offering a wider range of placement options. This allows for more flexible projector positioning and allows for a variety of image sizes.

IP5X dust-resistant optical unit

Independently tested and certified to IEC Standard 60529 with an IP5X dust resistance rating. Outstanding dust resistance combined with impressive brightness ensures industry-leading durability – essential for 24/7 operation in challenging environments.

Customize your projector

Choose from any color in the RAL color range and customize your projector's color to your liking. Perfect for customized installations.

*Please contact us for further information.

Full 3D

Optoma projectors can display 3D content from virtually any 3D source, including 3D compatible graphics cards, 3D delivery systems, and the latest generation of 3D media servers.

Network and control

Thanks to a variety of control options, the projector is easy to monitor and manage.

RS232

Optoma projectors can be easily monitored and controlled with virtually any control system thanks to a wide range of RS232 commands.

AMX compatibility

The Dynamic Discovery protocol built into the projector allows easy installation with any AMX control system.

LAN control

With compatible RoomView® software, you can turn up to 250 projectors on and off, monitor, and control them simultaneously from any PC.

Program the switching on and off

Control and adjust settings via a simple web browser.

Ability to send emergency messages.

Automatic reminder to change the lamp.

PJLink

The PJLink protocol built into the projector allows easy installation with PJLink compatible control systems.

Telnet

This model is capable of receiving commands via Telnet, allowing easy installation with Telnet-compatible control systems.

Flying/stacking racks available from Rigtec

Flying/stacking frames and various accessories are available for this model from Rigtec.

Contact [hello@rigtec.com][1] for more information

[1]: http://www.rigtec.com

Features

WUXGA DLP laser projector with high brightness | 17,000 lumens
Flexible installations | 8 interchangeable lenses
Highest reliability | Integrated redundancy mode
Impressively lifelike images | Pure Engine video processing and color adjustment
